Main Specifications | ||||||||||||||||||||||||
Dimensions (WxDxH) | Card PCB dimensions: 5.9in (14.99cm) x 2.73in (6.90cm) (L x H) | |||||||||||||||||||||||
Height of end brackets: standard - 4.725in (12cm), low-profile - 3.13in (7.94cm) | ||||||||||||||||||||||||
Form Factor | Low-Profile Standard Short-length Form Factor | |||||||||||||||||||||||
Interface (Bus) Type | PCI Express 3.0 (8GT/s) | |||||||||||||||||||||||
Device Type | Ethernet Controller | |||||||||||||||||||||||
Networking | ||||||||||||||||||||||||
Controller Type | Intel® XL710-BM1 | |||||||||||||||||||||||
Data Transfer Rate | 10GbE | |||||||||||||||||||||||
Port Quantity | Quad RJ45 connectors with speed up to 10Gb/s per port | |||||||||||||||||||||||
Virtualization Features | Next-Generation VMDq with up to 256 VMDq VMs supported, SR-IOV with up to 128 virtuals ports, Virtual Machine Load Balancing (VMLB), Advanced Packet Filtering, VLAN support for up to 4,096 VLAN tags, VXLAN and NVGRE support | |||||||||||||||||||||||
Power | ||||||||||||||||||||||||
Comsumtion Operational | 15.5W | |||||||||||||||||||||||
Environmental Parameters | ||||||||||||||||||||||||
Operating Temperature | Operating temperature: 0°C to 55°C (32°F to 131°F) | |||||||||||||||||||||||
Storage temperature: -40°C to 70°C (-40°F to 158°F) | ||||||||||||||||||||||||
Storage humidity: 90% non-condensing relative humidity at 35°C | ||||||||||||||||||||||||
Software / System Requirements | ||||||||||||||||||||||||
OS Supports | Windows® Server 2012 R2, 2012, 2008 R2 x86-64 | |||||||||||||||||||||||
Linux RedHat EL 6.5 and 7.0 IA-32, X86-64, and IA-64 | ||||||||||||||||||||||||
Linux SuSE SLES 11 SP3 and 12 IA-32, X86-64, and IA-64 | ||||||||||||||||||||||||
FreeBSD 9 and 10 IA-32, X86-64, and IA-64 | ||||||||||||||||||||||||
UEFI 2.1 and 2.3 X86-64 and I-64 | ||||||||||||||||||||||||
VMware ESXi 5.1 and ESXi 5.5 X86-64 | ||||||||||||||||||||||||
Miscellaneous | ||||||||||||||||||||||||
Features | Intel® Flow Director | |||||||||||||||||||||||
Multiple queues: 1,536 Tx and Rx queues per port | ||||||||||||||||||||||||
Tx/Rx IP, SCTP, TCP, and UDP checksum offloading (IPv4, IPv6) capabilities | ||||||||||||||||||||||||
MSI-X support to minimize interrupt overhead and to allow load-balancing be-tween multiple cores/CPUs | ||||||||||||||||||||||||
ROHS | RoHS compliant 6/6 |
Interfaz : | PCI-E |
Marca : | SUPERMICRO |
Puertos : | 4 x RJ45 |
Velocidad : | 10 GBPS |
