Main Specifications | |||||||||||||||||||||||||||||||||||||
Interface (Bus) Type | PCI-E 3.0 x8 (8GT/s, 5GT/s or 2.5GT/s) / Message Signal Interrupt (MSI-X) | ||||||||||||||||||||||||||||||||||||
Device Type | 25GbE controller | ||||||||||||||||||||||||||||||||||||
Dimensions (WxDxH) | 5.6” x 2.713” (14.224 x 6.89cm) | ||||||||||||||||||||||||||||||||||||
Form Factor | Low-Profile, Short Length Standard Form Factor | ||||||||||||||||||||||||||||||||||||
Card PCB dimensions: 14.2cm x 6.89cm (5.6in x 2.71in) (LxW) | |||||||||||||||||||||||||||||||||||||
Height of end brackets: standard – 12cm (4.725in), low-profile – 8cm (3.15in) | |||||||||||||||||||||||||||||||||||||
Weight | 89.58g (0.1975lb) | ||||||||||||||||||||||||||||||||||||
Networking | |||||||||||||||||||||||||||||||||||||
Port Quantity | Dual SPF28 Connectors | ||||||||||||||||||||||||||||||||||||
Data Transfer Rate | 25Gbps | ||||||||||||||||||||||||||||||||||||
Features | IEEE802.3ae 10 Gigabit Ethernet, IEEE802.3az Energy Efficient Ethernet, IEEE 802.3ap based auto-negotiation and KR startup, IEEE 802.ad, 802.1AX Link Aggregation, IEEE 802.1Q | ||||||||||||||||||||||||||||||||||||
802.1p VLAN tags and priority, IEEE802.1Qau (QCN) – Congestion Notification, IEEE 802.1Qaz (ETS), IEEE 802.1Qbb (PFC), IEEE 802.1Qbg, IEEE 1588v2, Jumbo frame support (9.6KB) | |||||||||||||||||||||||||||||||||||||
Virtualization Features | Single Root IOV, Multi-function per port, Address translation and protection, Multiple queues per virtual machine, Enhanced QoS for vNICs, VMware NetQueue support | ||||||||||||||||||||||||||||||||||||
Management Features | Asset Management features with thermal sensor | ||||||||||||||||||||||||||||||||||||
NC-SI for IPMI Support | |||||||||||||||||||||||||||||||||||||
SR-IOV: up to 256 Virtual Functions | |||||||||||||||||||||||||||||||||||||
SR-IOV: up to 16 Physical Functions per port | |||||||||||||||||||||||||||||||||||||
1K ingress and egress QoS levels | |||||||||||||||||||||||||||||||||||||
Guaranteed QoS for VMs | |||||||||||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||||||||||
Comsumtion Operational | 8.7W | ||||||||||||||||||||||||||||||||||||
Environmental Parameters | |||||||||||||||||||||||||||||||||||||
Operating Temperature | Operating temperature: 0°C to 55°C (32°F to 131°F) | ||||||||||||||||||||||||||||||||||||
Storage temperature: -40°C to 70°C (-40°F to 158°F) | |||||||||||||||||||||||||||||||||||||
Storage humidity: 90% non-condensing relative humidity at 35°C | |||||||||||||||||||||||||||||||||||||
Software / System Requirements | |||||||||||||||||||||||||||||||||||||
OS Supports | RHEL/CentOS, Windows, FreeBSD, VMware, OpenFabrics Enterprise Distribution (OFED), OpenFabrics Windows Distribution (WinOF-2), XenServer | ||||||||||||||||||||||||||||||||||||
Miscellaneous | |||||||||||||||||||||||||||||||||||||
Features | Asset Management Features with thermal sensor | ||||||||||||||||||||||||||||||||||||
Hardware offloads for VXLAN, NVGRE and GENEVE encapsulated traffic | |||||||||||||||||||||||||||||||||||||
Low latency RDMA over Converged Ethernet (RoCE) | |||||||||||||||||||||||||||||||||||||
PCI-SIG SR-IOV compliant | |||||||||||||||||||||||||||||||||||||
Jumbo Frames support up to 9.6kB | |||||||||||||||||||||||||||||||||||||
PXE support | |||||||||||||||||||||||||||||||||||||
Erasure Coding Offload | |||||||||||||||||||||||||||||||||||||
NC-SI for IPMI support | |||||||||||||||||||||||||||||||||||||
ROHS | RoHS compliant 6/6 | ||||||||||||||||||||||||||||||||||||
Designed For | Al MBs with a PCI-E x8 slot | ||||||||||||||||||||||||||||||||||||
All servers with a PCIE x8 slot | |||||||||||||||||||||||||||||||||||||
Vendor Compatible Products | Motherboards with minimum PCI-E 3.0 x8 expansion slot | ||||||||||||||||||||||||||||||||||||
Server Systems with low-profile or full-height PCI-E 3.0 x8 expansion slot | |||||||||||||||||||||||||||||||||||||
NC-SI feature is only supported by Supermicro® motherboards with corresponding NC-SI connectors |
Interfaz : | PCI-E |
Marca : | SUPERMICRO |
Puertos : | 2 x SPF+ |
Velocidad : | 25 GBPS |
