Main Specifications | |||||||||||||||||||||||||||||
Dimensions (WxDxH) | Card PCB dimensions: 15.49cm (6.1”) x 6.86cm (2.7”) | ||||||||||||||||||||||||||||
Height of end brackets: standard – 12cm (4.725in), low-profile – 7.94cm (3.13in) | |||||||||||||||||||||||||||||
Form Factor | Half-length low-profile standard form factor | ||||||||||||||||||||||||||||
Interface (Bus) Type | PCI-E 3.0 x8 | ||||||||||||||||||||||||||||
Weight | 127.69g (0.28lb) | ||||||||||||||||||||||||||||
Device Type | Network Adapter | ||||||||||||||||||||||||||||
Networking | |||||||||||||||||||||||||||||
Management Features | Asset Management features with thermal sensor | ||||||||||||||||||||||||||||
NC-SI for IPMI Support | |||||||||||||||||||||||||||||
Port Quantity | Dual SFP28 connectors | ||||||||||||||||||||||||||||
Virtualization Features | Next-Generation VMDq with up to 256 VMDq VMs supported | ||||||||||||||||||||||||||||
SR-IOV with up to 128 virtual ports | |||||||||||||||||||||||||||||
Virtual Machine Load Balancing (VMLB) | |||||||||||||||||||||||||||||
Advanced Packet Filtering | |||||||||||||||||||||||||||||
VLAN support for up to 4096 VLAN tags | |||||||||||||||||||||||||||||
VXLAN and NVGRE support | |||||||||||||||||||||||||||||
Power | |||||||||||||||||||||||||||||
Comsumtion Operational | 7.2W | ||||||||||||||||||||||||||||
Environmental Parameters | |||||||||||||||||||||||||||||
Operating Temperature | Operating temperature: 0°C to 55°C (32°F to 131°F) | ||||||||||||||||||||||||||||
Storage temperature: -40°C to 70°C (-40°F to 158°F) | |||||||||||||||||||||||||||||
Storage humidity: 90% non-condensing relative humidity at 35°C | |||||||||||||||||||||||||||||
Software / System Requirements | |||||||||||||||||||||||||||||
OS Supports | Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 | ||||||||||||||||||||||||||||
Linux: RHEL 6.9, Linux: RHEL 7.3, Linux: SLES 11 SP4, Linux: SLES 12 SP1, Linux Stable Kernel version 2.6/4.x | |||||||||||||||||||||||||||||
VMware vSphere 5.1, VMware vSphere 5.5, VMware vSphere 2015 (ESXi 6.0), VMware vSphere 2016 (ESXi 6.5) | |||||||||||||||||||||||||||||
Solaris | |||||||||||||||||||||||||||||
FreeBSD 10.3/11 | |||||||||||||||||||||||||||||
UEFI 2.1/2.3/2.4 | |||||||||||||||||||||||||||||
System Requirements Details | Motherboards with minimum PCI-E 3.0 x8 expansion slot | ||||||||||||||||||||||||||||
Server Systems with low-profile or full-height PCI-E 3.0 x8 expansion slot | |||||||||||||||||||||||||||||
NC-SI feature is only supported by Supermicro motherboards with corresponding NC-SI connectors | |||||||||||||||||||||||||||||
Miscellaneous | |||||||||||||||||||||||||||||
ROHS | RoHS Compliant 6/6, Pb Free |
Interfaz : | PCI-E |
Marca : | SUPERMICRO |
Puertos : | 2 x SPF+ |
Velocidad : | 25 GBPS |
