| Expansion Slots |
| |
| PCI-E |
- 1 PCI-E 3.0 x8 (in x16 slot),
- 1 PCI-E 3.0 x8,
- 1 PCI-E 3.0 x4 (in x8 slot)
|
| M.2 |
- M.2 Interface: PCI-E 3.0 x4 and SATA
- Form Factor: 2242, 2280, 22110
- Key: M-Key
- Double Height Connector
|
| |
| System BIOS |
| |
| BIOS Type |
- 128Mb SPI Flash EEPROM with AMI BIOS
|
| BIOS Features |
- ACPI 1.0 / 2.0 / 3.0 / 4.0
- SMBIOS 2.7.1
- APM 1.2
- DMI 2.3
- UEFI 2.3.1
- Hardware BIOS Virus protection
- USB Keyboard support
- RTC (Real Time Clock) Wakeup
|
| |
| Management |
| |
| Software |
- Intel® Node Manager, IPMI2.0, NMI, SPM, SSM, SUM, SuperDoctor® 5, Watchdog
|
| Power Configurations |
- ACPI Power Management
- Power-on mode for AC power recovery
|
| |
| PC Health Monitoring |
| |
| Voltage |
- +12V, +3.3V, +5V, +5V standby, Monitors CPU voltages, Supports system management utility, System level control, VBAT
|
| FAN |
- 5x 4-pin fan headers (up to 5 fans), Fan speed control, Overheat LED indication, Thermal control tachometer fan connectors
|
| Temperature |
- Monitoring for CPU and chassis environment, CPU thermal trip support, PECI, Thermal Monitor 2 (TM2) support
|
| LED |
- CPU / System Overheat LED, UID/Remote UID
|
| Other Features |
- Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, M.2 NGFF connector, VHD, WOL
|
| |
| Operating Environment |
| |
| Operating Temperature Range |
- 0°C ~ 50°C (32°F ~ 122°F)
|
| Non-Operating Temperature Range |
- -40°C - 70°C (-40°F - 158°F)
|
| Operating Relative Humidity Range |
- 8% - 90% (non-condensing)
|
| Non-Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
