| Expansion Slots |
| |
| PCI-E |
- 3 PCI-E 3.0 x8,
- 1 PCI-E 3.0 x16,
- 1 PCI-E 3.0 x8 (in x16 slot),
- 1 PCI-E 3.0 x4 (in x8 slot)
|
| M.2 |
- M.2 Interface: 1 PCI-E 3.0 x4
- Form Factor: 2280/22110
- Key: M-Key
- Double Height Connector
|
| |
| System BIOS |
| |
| BIOS Type |
|
| BIOS Features |
- ACPI 6.2
- SMBIOS 3.0 or later
- UEFI 2.7
|
| |
| Management |
| |
| Software |
- IPMI2.0, KVM with dedicated LAN, SUM, SuperDoctor® 5, Watchdog
|
| Power Configurations |
- ACPI Power Management
- CPU thermal trip support for processor protection
- Power-on mode for AC power recovery
|
| |
| PC Health Monitoring |
| |
| Voltage |
- +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, System temperature, VBAT
|
| FAN |
- 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control
|
| Temperature |
- PECI, CPU thermal trip support, Thermal Control for 6 Fan Connectors
|
| LED |
- CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED
|
| Other Features |
- ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, RoHS, UID
|
| |
| Operating Environment |
| |
| Operating Temperature Range |
- 0°C ~ 50°C (32°F ~ 122°F)
|
| Non-Operating Temperature Range |
- -20°C ~ 60°C (-4°F ~ 140°F)
|
| Operating Relative Humidity Range |
- 10% ~ 85% (non-condensing)
|
| Non-Operating Relative Humidity Range |
- 10% ~ 95% (non-condensing)
|
|
