| Expansion Slots |
| |
| PCI-E |
- 1 PCI-E 3.0 x8 (in x16 slot),
- 1 PCI-E 3.0 x32 Left Riser Slot
|
| M.2 |
- M.2 Interface: PCI-E 3.0 x4 and SATA
- Form Factor: 2280, 22110
- Key: M-Key
- Double Height Connector
|
| |
| System BIOS |
| |
| BIOS Type |
|
| BIOS Features |
- ACPI 6.0
- RTC (Real Time Clock) Wakeup
- SMBIOS 3.0 or later
|
| |
| Management |
| |
| Software |
- Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
|
| Power Configurations |
- ACPI Power Management
- Power-on mode for AC power recovery
|
| |
| PC Health Monitoring |
| |
| Voltage |
- +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, Supports system management utility, VBAT
|
| FAN |
- 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control
|
| Temperature |
- CPU thermal trip support, PECI
|
| LED |
- CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED
|
| Other Features |
- ACPI power management, Control of power-on for recovery from AC power loss, RoHS, UID, WOL
|
| |
| Operating Environment |
| |
| Operating Temperature Range |
- 0°C ~ 50°C (32°F ~ 122°F)
|
| Non-Operating Temperature Range |
- -40°C - 70°C (-40°F - 158°F)
|
| Operating Relative Humidity Range |
- 8% - 90% (non-condensing)
|
| Non-Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
