Main Specifications | ||||||||||||||||||||||||||
Dimensions (WxDxH) | Card PCB dimensions: 15cm x 6.89cm (5.9in x 2.71in) (LxW) | |||||||||||||||||||||||||
Form Factor | Compact size low-profile standard | |||||||||||||||||||||||||
Interface (Bus) Type | PCI-E 3.0 x4 (8GT/s, 5GT/s or 2.5GT/s) | |||||||||||||||||||||||||
Weight | 0.2455 lb | |||||||||||||||||||||||||
Height of end brackets: standard – 12cm (4.725in), low-profile – 8cm (3.15in) | ||||||||||||||||||||||||||
Networking | ||||||||||||||||||||||||||
Controller Type | Intel® X550-AT | |||||||||||||||||||||||||
Management Features | Asset Management features with thermal sensor | |||||||||||||||||||||||||
INC-SI for IPMI Support | ||||||||||||||||||||||||||
Port Quantity | Single RJ45 connectors with speed up to 10Gb/port | |||||||||||||||||||||||||
Virtualization Features | Multi-mode I/O Virtualization Operations, VXLAN, NVGRE, Virtual Machine Device Queues (VMDq), Next Generation VMDq, 64 Transmit (Tx) and Receive (Rx) Queue Pairs Per Port, Flexible Port Partitioning: 64 Virtual Functions Per Port, Support for PCI-SIG SR-IOV Specification, EEE 802.1Q VLAN | |||||||||||||||||||||||||
Power | ||||||||||||||||||||||||||
Details | 9W (-i1T) | |||||||||||||||||||||||||
Expansion / Connectivity | ||||||||||||||||||||||||||
Interface and Connections | 1 RJ45 (10GBase-T) | |||||||||||||||||||||||||
Environmental Parameters | ||||||||||||||||||||||||||
Operating Temperature | Operating temperature: 0°C to 55°C (32°F to 131°F) | |||||||||||||||||||||||||
Storage temperature: -40°C to 70°C (-40°F to 158°F) | ||||||||||||||||||||||||||
Storage humidity: 90% non-condensing relative humidity at 35°C | ||||||||||||||||||||||||||
Miscellaneous | ||||||||||||||||||||||||||
Cables Type | Cables Support: RJ-45 Category-6 up to 55m, Category-6A up to 100m | |||||||||||||||||||||||||
Features | Intel Flow Director | |||||||||||||||||||||||||
MSI-X Support | ||||||||||||||||||||||||||
Multiple Queues: 128 Tx and Rx Per Port | ||||||||||||||||||||||||||
TCP/UDP, IPv4 Checksum Offloads | ||||||||||||||||||||||||||
RSS for Windows Environment Scalable I/O for Linux Environments | ||||||||||||||||||||||||||
IPv6 Support for IP/TCP and IP/UDP Receive Checksum Offload | ||||||||||||||||||||||||||
Support for Packets Up to 15.5KB | ||||||||||||||||||||||||||
Large FC Receive | ||||||||||||||||||||||||||
DMA Coalescing | ||||||||||||||||||||||||||
ROHS | RoHS Compliant 6/6, Pb Free |
Interfaz : | PCI-E |
Marca : | SUPERMICRO |
Puertos : | 1 x RJ45 |
Velocidad : | 10 GBPS |
