Características
Essentials
- Product CollectionIntel® Xeon® E Processor
- Code NameProducts formerly Coffee Lake
- Vertical SegmentServer
- Processor NumberE-2124G
- StatusLaunched
- Launch DateQ3'18
- Lithography14 nm
- Use ConditionsEmbedded Broad Market Commercial Temp, PC/Client/Tablet
- Recommended Customer Price$213.00 - $218.00
Performance
- # of Cores4
- # of Threads4
- Processor Base Frequency3.40 GHz
- Max Turbo Frequency4.50 GHz
- Cache8 MB SmartCache
- Bus Speed8 GT/s DMI3
- TDP71 W
Supplemental Information
- Embedded Options AvailableYes
- DescriptionSupport for up to 128GB system memory capacity will be available in 2019 and requires both a BIOS update and hardware platform support. Please contact your hardware provider regarding availability for your system.
- DatasheetView now
Memory Specifications
- Max Memory Size (dependent on memory type)128 GB
- Memory TypesDDR4-2666
- Max # of Memory Channels2
- Max Memory Bandwidth41.6 GB/s
- ECC Memory Supported ‡Yes
Processor Graphics
- Processor Graphics ‡Intel® UHD Graphics P630
- Graphics Base Frequency350 MHz
- Graphics Max Dynamic Frequency1.15 GHz
- Graphics Video Max Memory128 GB
- Graphics OutputeDP/DP/HDMI/DVI
- 4K SupportYes, at 60Hz
- Max Resolution (HDMI 1.4)‡4096x2160@24Hz
- Max Resolution (DP)‡4096x2304@60Hz
- Max Resolution (eDP - Integrated Flat Panel)‡4096x2304@60Hz
- Max Resolution (VGA)‡N/A
- DirectX* Support12
- OpenGL* Support4.5
- Intel® Quick Sync VideoYes
- Intel® InTru™ 3D TechnologyYes
- Intel® Clear Video HD TechnologyYes
- Intel® Clear Video TechnologyYes
- # of Displays Supported ‡3
- Device ID0x3E96
Expansion Options
- Scalability1S Only
- PCI Express Revision3.0
- PCI Express Configurations ‡1x16,2x8,1x8+2x4
- Max # of PCI Express Lanes16
Package Specifications
- Sockets SupportedFCLGA1151
- Max CPU Configuration1
- Package Size37.5mm x 37.5mm
- Low Halogen Options AvailableNo
Advanced Technologies
- Intel® Optane™ Memory Supported ‡Yes
- Intel® Turbo Boost Technology ‡2.0
- Intel® vPro™ Platform Eligibility ‡Yes
- Intel® Hyper-Threading Technology ‡No
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d)‡Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡Yes
- Intel® TSX-NIYes
- Intel® 64 ‡Yes
- Instruction Set64-bit
- Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle StatesYes
- Enhanced Intel SpeedStep® TechnologyYes
- Thermal Monitoring TechnologiesYes
Security & Reliability
- Intel® AES New InstructionsYes
- Secure KeyYes
- Intel® Software Guard Extensions (Intel® SGX)Yes with Intel® ME
- Intel® Memory Protection Extensions (Intel® MPX)Yes
- Intel® OS GuardYes
- Intel® Trusted Execution Technology ‡Yes
- Execute Disable Bit ‡Yes
- Intel® Boot GuardYes
Ficha técnica
| Socalo de CPU : | 1151 |
| Tipo de Memoria : | DDR4 RDIMM |
| Cache : | 8MB |
| Cores : | 4 |
| Frequencia : | 3.4G |
| Marca : | INTEL |
| Memoria RAM maxima : | 128GB |
| Threads : | 4 |
