Características
Essentials
- Product CollectionIntel® Xeon® Processor E3 v6 Family
- Code NameProducts formerly Kaby Lake
- Vertical SegmentServer
- Processor NumberE3-1245V6
- StatusLaunched
- Launch DateQ1'17
- Lithography14 nm
- $284.00 - $294.00
Performance
- # of Cores4
- # of Threads8
- Processor Base Frequency3.70 GHz
- Max Turbo Frequency4.10 GHz
- Cache8 MB SmartCache
- Bus Speed8 GT/s DMI3
- TDP73 W
- VID Voltage Range0.55V-1.52V
Supplemental Information
- Embedded Options AvailableNo
- DatasheetView now
Memory Specifications
- Max Memory Size (dependent on memory type)64 GB
- Memory TypesDDR4-2400, DDR3L-1866
- Max # of Memory Channels2
- Max Memory Bandwidth37.5 GB/s
- ECC Memory Supported ‡Yes
Processor Graphics
- Processor Graphics ‡Intel® HD Graphics P630
- Graphics Base Frequency350 MHz
- Graphics Max Dynamic Frequency1.15 GHz
- Graphics Video Max Memory64 GB
- Graphics OutputeDP/DP/HDMI/DVI
- 4K SupportYes, at 60Hz
- Max Resolution (HDMI 1.4)‡4096x2160@24Hz
- Max Resolution (DP)‡4096x2304@60Hz
- Max Resolution (eDP - Integrated Flat Panel)‡4096x2304@60Hz
- Max Resolution (VGA)‡N/A
- DirectX* Support12
- OpenGL* Support4.4
- Intel® Quick Sync VideoYes
- Intel® InTru™ 3D TechnologyYes
- Intel® Clear Video HD TechnologyYes
- Intel® Clear Video TechnologyYes
- # of Displays Supported ‡3
- Device ID0x591D
Expansion Options
- Scalability1S Only
- PCI Express Revision3.0
- PCI Express Configurations ‡1x16, 2x8, 1x8+2x4
- Max # of PCI Express Lanes16
Package Specifications
- Sockets SupportedFCLGA1151
- Max CPU Configuration1
- Package Size37.5mm x 37.5mm
- Low Halogen Options AvailableNo
Advanced Technologies
- Intel® Optane™ Memory Supported ‡Yes
- Intel® Turbo Boost Technology ‡2.0
- Intel® vPro™ Platform Eligibility ‡Yes
- Intel® Hyper-Threading Technology ‡Yes
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d)‡Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡Yes
- Intel® TSX-NIYes
- Intel® 64 ‡Yes
- Instruction Set64-bit
- Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle StatesYes
- Enhanced Intel SpeedStep® TechnologyYes
- Thermal Monitoring TechnologiesYes
Security & Reliability
- Intel® AES New InstructionsYes
- Secure KeyYes
- Intel® Software Guard Extensions (Intel® SGX)Yes with Intel® ME
- Intel® Memory Protection Extensions (Intel® MPX)Yes
- Intel® OS GuardYes
- Intel® Trusted Execution Technology ‡Yes
- Execute Disable Bit ‡Yes
- Intel® Boot GuardYes
Ficha técnica
| Socalo de CPU : | 1151 |
| Tipo de Memoria : | DDR4 UDIMM |
| Cache : | 8MB |
| Cores : | 4 |
| Frequencia : | 3.7G |
| Marca : | INTEL |
| Memoria RAM maxima : | 64GB |
| Threads : | 8 |
