| Expansion Slots |
| |
| PCI-E |
- 3 PCI-E 3.0 x16,
- 1 PCI-E 3.0 x4
- ***3xPCI-E3.0 x16 Slots(8/16/16 (Skylake-W 48 lanes)), 1xPCI-E3.0x4 slots***
|
| M.2 |
- M.2 Interface: 2 PCI-E 3.0 x4
- Form Factor: 22110
- Key: M-Key (RAID 0,1 support)
- *M-Key for SSD and Optane(up to Intel POR). Intel VROC licence kit is needed to enable RAID.
|
| |
| Management |
| |
| Software |
- IPMI2.0, SuperDoctor® 5, Watchdog
|
| |
| PC Health Monitoring |
| |
| Voltage |
- +1.8V, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, 5 (4-pin), Chassis intrusion header, Monitors CPU voltages, Monitors for CPU Cores, System temperature, VBAT
|
| FAN |
- 5x 4-pin fan headers (up to 5 fans), Fan speed control, Overheat LED indication, PWM fan speed control
|
| Temperature |
- CPU thermal trip support, Monitoring for CPU and chassis environment, PECI, Support to monitor Supermicro AOC temperatures from IPMI or SD 5
|
| LED |
- CPU / System Overheat LED
|
| Other Features |
- ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Intel Smart Response Technology, RoHS, Voltage and Frequency Overclocking, WOL
|
| |
| Operating Environment |
| |
| Operating Temperature Range |
- 0°C ~ 50°C (32°F ~ 122°F)
|
| Non-Operating Temperature Range |
- -20°C ~ 60°C (-4°F ~ 140°F)
|
| Operating Relative Humidity Range |
- 10% ~ 85% (non-condensing)
|
| Non-Operating Relative Humidity Range |
- 10% ~ 95% (non-condensing)
|
|
