Intel® Xeon® Processor E5-2658 v4

US$ 6661.92
Agregar al Carrito
Intel® Xeon® Processor E5-2658 v4
Favoritos Consultar
Comparar

Essentials

Performance

  • # of Cores14
  • # of Threads28
  • Processor Base Frequency2.30 GHz
  • Max Turbo Frequency2.80 GHz
  • Cache35 MB SmartCache
  • Bus Speed9.6 GT/s QPI
  • # of QPI Links2
  • TDP105 W
  • VID Voltage Range0

Supplemental Information

  • Embedded Options AvailableYes
  • DatasheetView now

Memory Specifications

  • Max Memory Size (dependent on memory type)1.5 TB
  • Memory TypesDDR4 1600/1866/2133/2400
  • Max # of Memory Channels4
  • Max Memory Bandwidth76.8 GB/s
  • Physical Address Extensions46-bit
  • ECC Memory Supported ‡Yes

Expansion Options

  • Scalability2S
  • PCI Express Revision3.0
  • PCI Express Configurations ‡x4, x8, x16
  • Max # of PCI Express Lanes40

Package Specifications

  • Sockets SupportedFCLGA2011-3
  • Max CPU Configuration2
  • TCASE91°C
  • Package Size45mm x 52.5mm
  • Low Halogen Options AvailableNo

Advanced Technologies

  • Intel® Turbo Boost Technology ‡2.0
  • Intel® vPro™ Platform Eligibility ‡Yes
  • Intel® Hyper-Threading Technology ‡Yes
  • Intel® Virtualization Technology (VT-x) ‡Yes
  • Intel® Virtualization Technology for Directed I/O (VT-d)‡Yes
  • Intel® VT-x with Extended Page Tables (EPT) ‡Yes
  • Intel® TSX-NIYes
  • Intel® 64 ‡Yes
  • Instruction Set64-bit
  • Instruction Set ExtensionsIntel® AVX2
  • Idle StatesYes
  • Enhanced Intel SpeedStep® TechnologyYes
  • Intel® Demand Based SwitchingYes
  • Thermal Monitoring TechnologiesYes
  • Intel® Flex Memory AccessNo
  • Intel® Identity Protection Technology ‡No

Security & Reliability

  • Intel® AES New InstructionsYes
  • Secure KeyYes
  • Intel® OS GuardYes
  • Intel® Trusted Execution Technology ‡Yes
  • Execute Disable Bit ‡Yes
Socalo de CPU : 2011
Tipo de Memoria : DDR4 RDIMM
Cache : 35.5MB
Cores : 14
Frequencia : 2.3G
Marca : INTEL
Memoria RAM maxima : 1.5TB
Threads : 28
