Main Specifications | ||||||||||||||
Interface (Bus) Type | x8 lane PCI Express® 3.0 | |||||||||||||
Dimensions (WxDxH) | H x L 2.7" x 6.6" | |||||||||||||
Device Type | Add-on Card | |||||||||||||
Storage Controller | ||||||||||||||
Channel Quantity | 8-port (internal), 12Gb/s per port | |||||||||||||
Data Transfer Rate | Supports 3.0, 6.0 and 12Gb Gb/s SAS and SATA data transfer rates | |||||||||||||
Processor | Processor at 1.2 GHZ | |||||||||||||
Software / System Requirements | ||||||||||||||
OS Required | Windows 2012, 2k8,Vista, RedHat Enterprise and SUSE Linux | |||||||||||||
Miscellaneous | ||||||||||||||
Compatible Products | Motherboards: X9DRH-7TF, X9DR3-LN4F+, X9DRT-PIBQ, X9DRT-P | |||||||||||||
RoHS | RoHS Compliant 6/6, Pb Free | |||||||||||||
Features | Supports SSP, SMP, STP and SATA protocols | |||||||||||||
Power management support | ||||||||||||||
Port independent auto-negotiation | ||||||||||||||
Automatically negotiates PCI-E (1.x, 2.x and 3.x) link widths | ||||||||||||||
Zoning capability w/ SAS3 expanders |
Cantidad de puertos Internos : | 8 internal SAS3 |
Marca : | SUPERMICRO |
